The Blackmagic PYXIS 12K combines Blackmagic's latest 12K full-frame RGBW sensor with a compact, modular design built for modern cinema productions. Delivering 16 stops of dynamic range, Blackmagic RAW recording, and exceptional oversampled 8K and 4K image quality, it offers outstanding flexibility for narrative, commercial, documentary, and virtual production workflows.

Designed to adapt to virtually any shooting configuration, the PYXIS features a lightweight aluminum body, interchangeable PL, L-Mount, and Locking EF options, dual CFexpress recording, and seamless integration with DaVinci Resolve.

Technical Specifications

• Sensor: 36 × 24 mm Full Frame RGBW Sensor

• Resolution: Up to 12K Open Gate (12,288 × 8,040)

• Dynamic Range: 16 Stops

• Recording Format: Blackmagic RAW + H.264 Proxy

• Recording Media: Dual CFexpress Type B

• Frame Rates: Up to 40 fps (12K Open Gate), up to 112 fps (8K)

• Lens Mount: PL / L-Mount / Locking EF

• Display: 4" HDR Touchscreen

• Outputs: 12G-SDI, USB-C, Ethernet

• Power: Sony BP-U Batteries or 2-pin LEMO DC Input

• Weight (Body Only): Approx. 1.5 kg
